HellermannTyton CCP-SAA Connection Point with SC-APC Simplex Adapter PC, White
TheHellermannTyton CCP-SAA-W is a Customer Connection Point (CCP) manufacturedfrom UL 94 V-0 and UV stable black polycarbonate and has a fully detachablesnap-on lid. The closure has two separate cable access points, which are sealedwith a silicon cable entry kit (cable diameter range 4.6 mm – 5.6 mm) tomaintain the IP68 rating. A GORE-TEX breather membrane is fitted to the lid toprevent condensation forming in the base of the closure. The unit can besupplied with one SC Simplex or LC Duplex and matching pigtails and providessplice management for two heat shrink splices. Internal fiber managementfeatures ensure that a 30 mm minimum bend radius is maintained within theclosure and provides fiber storage capacity for any excess fiber.
Key Features
- Fully watersealed, achieving an IP-68 (NEMA 6P) rating, for use in wall or handholeinstallations
- Separateinbound/outbound access points ensure cable sealing and segregation
- Singlesubscriber splice or patch to connect a home or outdoor device
TechnicalSpecifications
Max Cable Diameter
0.22″
Min Cable Diameter
0.18″
Connector Type
SC-APC
Dimensions (WxDxH)
3.5 x 1.1 x6.3″
Installed Adapters
1
Pigtals Installed
0
Splice Quantity
2
Color
White
