Lowell ACR-SEQ6-2009 20A Rackmount Sequencer
Rackmountpanel with nine outlets (six switched, three un-switched) and sequencer forsequential activation/deactivation of connected equipment. Includes alarm interface.
TechnicalSpecifications
Chassis
19 in. x 9in. x 1.75 in. (1U)
Power Rating
120VAC 60Hz,20A
Termination
9 ft.attached cord with NEMA plug
Activation
Rockerswitch
Outlets (9 total)
1 front(15A) un-switched, 2 rear(15A) un-switched , 6 rear (15A) switched.
Four stepsequential power plus two dry contact closures (steps 5 and 6) for triggeringremote power control units (RPC series, order separately).
Adjustabledelay between sequenced steps
Reartermination blocks accommodate remote switches, external triggers and an alarmsystem interface for use where mandated by fire code.
Alarm Interface
Lock on/offand switch lock functions for alarm system or master control panelapplications.
External Control Connections
Plug-inbarrier strip terminal blocks
