12-Pair Multicore
- For studio purposes as well as permanent installations
- High-quality model
- Sold by the metre
Features:
- Completely torsion-free
- Cold-resistant up to -30°
- Individually with rubber tubes insulated wire pairs
- Cu-coil shielded with 100% coverage
- Low capacitance of 45 pF cable/cable
- 110 Ohm (AES/EBU compliant over hundreds of metres)
Technical data:
- Cable cross-section: 0.22 mm²
- Sheath: S-PVC
- AWG – AWG24
- Conductor insulation: Skin PE
- Shielded
- AL/PT foil + screen + stranded drain wire – 100%
- Temperature range: -30° to +70°
- Sheath colour: Black, matte
- Diameter 17.6 mm
- Electrical data: capacity wire/wire at 1m – 46 pF
- Capacitance wire/shield at 1 m: 130 pF
- Conductor resistance: 1Km <80 Ohm
- Insulation resistance: 1 km:> 1 GOhm
- Characteristic impedence: 110 Ohm
- Available sinceOctober 2013
- Item number320905
- Sales Unit1 metre(s)
