Overview of The Light Source – Mega-Batten Clamp, Mill Finish
The two-piece, Mega Batten Clamp is great way to hang 1-1/2″ pipe. The tight compression fit keeps pipe from rotating within the clamp. The Mega Batten Clamp wraps around the pipe batten on both sides and fastens with two 5/16″-18 TPI Socket Cap Screws using a 1/4″ hex driver. Secure to structural supports through nominal 1/2″ hole at top of clamp with up to a 1/2″ shackle pin, quick link, or turnbuckle jaw. CNC Machined 3/16″ thick x 2″ wide 6061T-6 Aluminum.
Music City Canada is an authorized reseller for The Light Source products.Purchases are backed with full manufacturer warranty in Canada. All orders ship from our Canadian warehouse.
